MPC-Hammer-head fasteners 27/18 - 28/30 galvanised | 27/18, 28/30 | M10 | 35 mm

MPC-Hammer-head fasteners 27/18 - 28/30

MPC-Hammer-head fastener M10 x 35 mm for profiles 27/18-28/30, galvanised

Display variants as list
Reset selection
Art.no.: 115104
Surface: galvanised
For profiles: 27/18, 28/30
Connecting thread: M10
Length: 35 mm
Sales unit: 100 Pieces
Weight/item: 0.069 kg
Pieces

Field of application

  • For time-saving, efficient attachment of pipe clamps to MPC-Support channels

Advantages

  • Practical range of lengths
  • For insertion at any point into the slot of channel support profiles 27/18 and 28/30
  • Lateral adjustment at any time, allows perfect alignment of the pipeline after installation
  • Various lengths and thread diameters can be combined within the same channel
  • Supplied with with washers and hexagonal nuts
Basic data text:
MPC-Hammer-head fastener M10 x 35 mm for profiles 27/18-28/30, galvanised
Support channels:
for MPC-Profiles
Product type:
Connecting parts
For profiles:
27/18, 28/30
Material:
Steel
Surface:
galvanised
Connecting thread:
M10
Length:
35 mm
Usable thread length:
18 mm
Customs tariff number:
73181900
