Field of application

  • Suitable for pipe attachments in industrial areas
  • Suitable for fastening of drinking water and heating pipes
  • For indoor use

Advantages

  • Proven two-piece clamp
  • High stiffness due to reinforcing bead
  • The 2 locking screws allow adjustment to accommodate a greater variation in pipe diameter
  • Tightening bolts with combination cross-head convenient for power driver
  • Fastener screws with captive washer
  • Connecting thread with combithread M8/M10
  • DÄMMGULAST® vibration control lining with green identification stripe: average sound level improvement up to 18 dB(A)
  • Vibration control tested
Product type:
Pipe clamps medium load range
Vibration control lining:
DÄMMGULAST® green
Surface:
galvanised
Average vibration reduction:
18 dB(A)
